Fractal Design Core 1100 Computer Case

General Information

• Manufacturer: Fractal Design
• Manufacturer Part Number: FD-CA-CORE-1100-BL
• Manufacturer Website Address: http://www.fractal-design.com
• Brand Name: Fractal Design
• Product Line: Core
• Product Series: X3
• Product Model: FD-CA-CORE-1100-BL
• Product Name: Core 1100
• Marketing Information: This compact micro ATX case is optimized for airflow with a straight cooling path, a pre-installed 120mm fan, and dust filters in the front panel. The innovative vertical hard drive bracket supports two 3.5" drives, three 2.5" drives, or one of each. Both 3.5" drive slots feature silicone vibration dampening grommets. It boasts a brushed aluminum-look front panel with a three-dimensional textured finish, a fully painted interior with Fractal Design's signature white details, and easy-access front panel I/O with audio, USB 3.0, and USB 2.0 ports. Closed top and bottom panels help maintain a dust-free interior.

Technical Information

• Product Type: Computer Case
• Motherboard Supported: Micro ATX, Mini ITX
• Number of Fans Supported: 1
• Number of Fans Installed: 1
• Fan Size Supported: 4.72" (120mm)
• Installed Fan Size: 4.72" (120mm) - 1 x 120mm Fractal Design fan included
• Features: Dust Filter, Smart HDD Bracket (vertical, supports two 3.5" drives, three 2.5" drives, or one of each, with vibration-dampened mounting for 3.5" drives)

Bays

• Number of Internal 3.5" Bays: 2
• Number of Internal 2.5" Bays: 3

I/O Expansions

• Total Number of Expansion Slots: 4

Interfaces/Ports

• Total Number of USB Ports: 2 (1 x USB 3.0, 1 x USB 2.0)
• Total Number of Audio In Ports: 1 (Front Audio In: Yes)
• Total Number of Audio Out Ports: 1 (Front Audio Out: Yes)

Physical Characteristics

• Color Family: Black
• Product Color: Black
• Product Material: Brushed Aluminum (Brushed aluminum-look front panel with a sleek, three-dimensional textured finish)
• Cooler Type: Fan/Liquid Cooler
• Maximum CPU Cooler Height: 5.83"
• Maximum PSU Length: 7.28"
• Maximum GPU Length: 13.78"
• Height: 14.1"
• Width: 6.9"
• Depth: 16.1"
• Weight (Approximate): 8.38 lb

Warranty

• Limited Warranty: 2 Year
