Brand: AMD
SKU: CPUAM5-8700G

AMD Ryzen 7 8700G | 8-Core Up to 5.1 GHz Processor | AM5 Socket | CPU Cooler Included | Integrated Graphics

Product Model:: Ryzen 7 8700G
CPU Socket: AM5
CPU Type: Ryzen 7
Brand: AMD
UPC/EAN: 730143316125
Advanced Micro Devic AMD Ryzen 7 8700G Octa-core (8 Core) 4.20 GHz Processor - Retail Pack - 16 MB L3 Cache - 8 MB L2 Cache - 64-bit Processing - 5.10 GHz Overclocking Speed - 4 nm - Socket AM5 - AMD Radeon 780M Yes Graphics - 65 W - 16 Threads
Product Details
AMD Ryzen™ 7 8700G with AMD Ryzen AI is the ultimate all-in-one desktop processor with AMD Radeon™ 780M Graphics capabilities
PC PERFORMANCE  AND VALUE YOU CAN COUNT ON.  AMD Ryzen 7 8700G 8 Cores and 16 processing threads, with advanced AMD "Zen 4" architecture. 5.0 GHz Max Boost, unlocked for overclocking, DDR5 support. For the state-of-the-art Socket AM5 platform, it is upgradable for years to come. AMD Wraith Spire Cooler Included

  • General Specifications

    Name
    AMD Ryzen™ 7 8700G
    Family
    Ryzen
    Series
    Ryzen 8000 Series
    Form Factor
    Desktops
    AMD PRO Technologies
    No
    Consumer Use
    Yes
    Regional Availability
    Global
    Former Codename
    Phoenix
    Architecture
    Zen 4
    # of CPU Cores
    8
    Multithreading (SMT)
    Yes
    # of Threads
    16
    Max. Boost Clock Learn More.

    up to 5.1 GHz
    Base Clock
    4.2 GHz
    L2 Cache
    8 MB
    L3 Cache
    16 MB
    Default TDP
    65W
    AMD Configurable TDP (cTDP)
    45-65W
    Processor Technology for CPU Cores
    TSMC 4nm FinFET
    CPU Compute Die (CCD) Size
    178mm²
    Package Die Count
    1
    Unlocked for Overclocking
    Yes
    AMD EXPO™ Memory Overclocking Technology
    Yes
    Precision Boost Overdrive
    Yes
    Curve Optimizer Voltage Offsets
    Yes
    AMD Ryzen™ Master Support
    Yes
    CPU Socket
    AM5
    CPU Boost Technology
    Precision Boost 2
    Instruction Set
    x86-64
    Supported Extensions
    AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64
    Max. Operating Temperature (Tjmax)
    95°C
    Launch Date
    1/31/2024
    *OS Support
    Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , RHEL x86 64-Bit , Ubuntu x86 64-Bit

  • Connectivity

    Native USB 4 (40Gbps) Ports
    2
    Native USB 3.2 Gen 2 (10Gbps) Ports
    2
    Native USB 2.0 (480Mbps) Ports
    1
    PCI Express® Version
    PCIe® 4.0
    Native PCIe® Lanes (Total/Usable)
    20 , 16
    NVMe Support
    Boot , RAID0 , RAID1
    System Memory Type
    DDR5
    Memory Channels
    2
    Max. Memory
    256 GB
    System Memory Subtype
    UDIMM
    Max Memory Speed
    2x1R
    DDR5-5200
    2x2R
    DDR5-5200
    4x1R
    DDR5-3600
    4x2R
    DDR5-3600

  • Graphics Capabilities

    Graphics Model
    AMD Radeon™ 780M
    Graphics Core Count
    12
    Graphics Frequency
    2900 MHz
    DirectX® Version
    12
    DisplayPort™ Version
    2.1
    DisplayPort Extensions
    Adaptive-Sync , HDR Metadata , UHBR10
    DisplayPort Max Refresh Rates (SDR)
    7680x4320 @ 60Hz , 3840x2160 @ 240Hz , 3440x1440 @ 360Hz , 2560x1440 @ 480Hz , 1920x1080 @ 600Hz
    DisplayPort Max Refresh Rates (HDR)
    7680x4320 @ 60Hz , 3840x2160 @ 240Hz , 3440x1440 @ 360Hz , 2560x1440 @ 480Hz , 1920x1080 @ 600Hz
    HDMI® Version
    2.1
    HDCP Version Supported
    2.3
    USB Type-C® DisplayPort™ Alternate Mode
    Yes
    Multi-Monitor Support
    Yes
    Max Displays
    4
    AMD FreeSync™
    Yes
    Wireless Display
    Miracast
    Max Video Encode Bandwidth (SDR)

    1080p630 8bpc H.264, 1440p373 8bpc H.264, 2160p175 8bpc H.264, 1080p630 8bpc H.265, 1440p373 8bpc H.265, 2160p175 8bpc H.265, 4320p43 8bpc H.265, 1080p864 8/10bpc AV1, 1440p513 8/10bpc AV1, 2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1

    Max Video Decode Bandwidth

    1080p60 8bpc MPEG2, 1080p60 8bpc VC1, 1080p786 8/10bpc VP9, 2160p196 8/10bpc VP9, 4320p49 8/10bpc VP9, 1080p1200 8bpc H.264, 2160p300 8bpc H.264, 4320p75 8bpc H.264, 1080p786 8/10bpc H.265, 2160p196 8/10bpc H.265, 4320p49 8/10bpc H.265, 1080p960 8/10bpc AV1, 2160p240 8/10bpc AV1, 4320p60 8/10bpc AV1

    AMD SmartAccess Memory
    Available

  • AI Engine Capabilities

    Brand Name
    AMD Ryzen™ AI
    AMD Ryzen™ AI
    Available
    Performance
    Up to 16 TOPS

Weight: 2 lbs
100-100001236BOX
